CM42 Mini Dome

High resolution, general purpose indoor dome with intelligent edge-based video analytics.

5MP

Image Resolution

79°

Horizontal FoV (After LDC)

20M

Image Resolution

Accessory List

Wall Mounting

ACC-MNT-SJBOX-1

Square Junction Box

Mount, conceal, and protect – the ultimate solution for hiding wires and connectors and achieving a sleek, professional look.

ACC-MNT-MJBOX-1

Mini Junction Box Mount

For mounting a mini camera to a standard junction box.

ACC-MNT-ARM-1

Arm Mount

Wall mounted extender arm with built in 1.5” female NPT thread.

ACC-MNT-8

Pendant Cap Mount Kit

Threaded cap that attaches to the rear of a camera.

ACC-MNT-POLE-1

Pole Mount

For mounting cameras to circular poles 2″ to 6″ in diameter.

ACC-MNT-POLE-1

Pole Mount

For mounting cameras to circular poles 2″ to 6″ in diameter.

ACC-MNT-ARM-1

Arm Mount

Wall mounted extender arm with built in 1.5” female NPT thread.

ACC-MNT-8

Pendant Cap Mount Kit

Threaded cap that attaches to the rear of a camera.

ACC-MNT-SJBOX-1

Square Junction Box

Mount, conceal, and protect – the ultimate solution for hiding wires and connectors and achieving a sleek, professional look.

ACC-MNT-MJBOX-1

Mini Junction Box Mount

For mounting a mini camera to a standard junction box.

ACC-MNT-CORNER-1

Corner Mount

Mount for installing cameras and accessories to external corners.

ACC-MNT-CORNER-1

Corner Mount

Mount for installing cameras and accessories to external corners.

ACC-MNT-ARM-1

Arm Mount

Wall mounted extender arm with built in 1.5” female NPT thread.

ACC-MNT-8

Pendant Cap Mount Kit

Threaded cap that attaches to the rear of a camera.

ACC-MNT-CLIP-1

Tile Clip

For mounting indoor Dome, Mini and Fisheye cameras to commercial ceiling tile rails from 9/16″ to 15/16″ wide without the requirement to drill. Customers may still wish to drill a hole to properly conceal the cable.

ACC-MNT-MPEND-1

Mini Pendant Cap Mount

Threaded cap for mounting a mini camera to 3/4″ NPT threaded drop pipe and 1.5″ NPT threads.

Product Specifications

Product Specifications

Download PDF
Full Install Guide

Camera features

  • Image Sensor
    1 / 2.8" Progressive CMOS
  • Sensor Resolution1
    5MP (2592 x 1944)
  • Lens Type
    Fixed
  • Focal Length
    2.8mm
  • Aperture
    F1.6
  • Iris
    Fixed
  • Field of View (after LDC2)
    Horizontal: 95° (79°)
    Vertical: 69° (62°)
    Diagonal: 130° (96°)
  • Sensor Movement
    Tilt: 60°
    Pan: 350°
    Rotation: 180°
  • Shutter Speed
    1 / 30 sec. to 1 / 10,000 sec.
  • Day/Night
    IR-cut filter for day and night function
  • IR Cut Filter
    Yes
  • IR Range
    20m / 66ft
  • Minimum Illumination
    0.009 lux @ F1.9 (Color)
    0 lux with IR Illuminators on
  • Onboard Storage
    Capacity: From 256GB to 2TB
    Card: MicroSD, SDXC
  • CPU
    Ambarella CV25S88

Standard video settings

  • Compression
    H.265, H.264
  • Frame Rate4
    24fps
  • Live Streaming Settings
    High quality (HQ): Up to 3,000 Kbps (default)
    Standard quality (SQ): Up to 600 Kbps
  • Historical Video Settings
    Adaptive quality1
  • WDR Technology
    104 dB dynamic range, true WDR, dual exposure

Standard audio settings

  • Audio
    Supported
  • Audio Capacity
    One-way audio
  • Interface
    Built-in microphone
  • Effective Range
    5m / 15ft

Power and network

  • Power Input3
    With IR: IEEE 802.3af Type 1 PoE
    Without IR: IEEE 802.3af Type 1 PoE
    Extended temperature range: N/A
  • Power Consumption
    With IR: 37-57V, 0.165-0.107A, 6.12W
    Without IR: 37-57V, 0.086-0.056A, 3.21W
    Extended temperature range: N/A
  • Connectivity
    RJ-45 cable connector for network/PoE connection; 10 / 100 / 1000 Mbps
  • RTSP
    RTSP 1.0
    RFC 2326
    Max concurrent streams: 2
    Audio support: Yes

General

  • Operating Temperature
    -10°C to 50°C / 14°F to 122°F
  • Humidity
    0 to 90%
  • Certifications
    For hardware certification information, please visit verkada.com/compliance
  • LED Indicator
    System power and status indicator
  • Warranty
    10 Years
  • Included Accessories
    Setup guide, T10 security torx screwdriver, 3x wingnuts, 3x washers, 3x TP4.0 mount screws, 3x M4 wall screws, 3x wall anchors

Mechanical

  • Weight
    Camera: 290g / 10.23oz
    Mount plate: 98g / 3.46oz
  • Dimensions
    Ø: 124.5mm / 4.9in, H: 71.5mm / 2.8in
  • Body
    Aluminum, plastic dome trim

Software capabilities

  • Alerts
    Camera status, motion detection, people detection, vehicle detection, Person of Interest detection, crowd detection, line-crossing detection, loitering detection
  • Streaming and storage
    Cloud backup, configurable retention days, selectable storage location, low bandwidth mode, timelapse, RTSP
  • People analytics
    People search, attribute search, face search, Occupancy Trends, motion search, trajectory analysis, selective face blurring, AI-powered search5
  • Sharing and privacy
    Live Links, live face blur, privacy regions, audit log
  • Vehicle analytics
    Vehicle search, attribute search, motion search, trajectory analysis, Occupancy Trends, AI-powered search5

1 All our cameras record in "adaptive quality", capturing both standard and high quality streams. Standard quality (SQ) video is stored up to the amount of retention specified by the customer. The amount of high quality video stored on the camera will depend on the amount of motion detected by the camera over time. To learn more, visit our website: https://docs.verkada.com/docs/adaptive-quality-recording-whitepaper.pdf

2 Lens Distortion Correction (LDC) crops the sensor field of view to deliver a rectified, undistorted output image.

3 Extended temperature range includes operating temperatures below -8.5°C / 16.7°F and assumes IR will be enabled.

4 Frame rate can be adjusted by support.

5 AI-powered search is currently supported in English only.
