CM41-E Outdoor Mini Dome

Durable, discreet mini dome built for outdoor and high-traffic environments.

5MP

Image Resolution

78°

Horizontal FoV (After LDC)

IP67

and IK10 Rated

15M

Image Resolution

Accessory List

Wall Mounting

ACC-MNT-SJBOX-1

Square Junction Box

Mount, conceal, and protect – the ultimate solution for hiding wires and connectors and achieving a sleek, professional look.

ACC-MNT-MJBOX-1

Mini Junction Box Mount

For mounting a mini camera to a standard junction box.

ACC-MNT-ARM-1

Arm Mount

Wall mounted extender arm with built in 1.5” female NPT thread.

ACC-MNT-8

Pendant Cap Mount Kit

Threaded cap that attaches to the rear of a camera.

ACC-MNT-POLE-1

Pole Mount

For mounting cameras to circular poles 2″ to 6″ in diameter.

ACC-MNT-POLE-1

Pole Mount

For mounting cameras to circular poles 2″ to 6″ in diameter.

ACC-MNT-ARM-1

Arm Mount

Wall mounted extender arm with built in 1.5” female NPT thread.

ACC-MNT-8

Pendant Cap Mount Kit

Threaded cap that attaches to the rear of a camera.

ACC-MNT-SJBOX-1

Square Junction Box

Mount, conceal, and protect – the ultimate solution for hiding wires and connectors and achieving a sleek, professional look.

ACC-MNT-MJBOX-1

Mini Junction Box Mount

For mounting a mini camera to a standard junction box.

ACC-MNT-CORNER-1

Corner Mount

Mount for installing cameras and accessories to external corners.

ACC-MNT-CORNER-1

Corner Mount

Mount for installing cameras and accessories to external corners.

ACC-MNT-ARM-1

Arm Mount

Wall mounted extender arm with built in 1.5” female NPT thread.

ACC-MNT-8

Pendant Cap Mount Kit

Threaded cap that attaches to the rear of a camera.

Product Specifications

Product Specifications

Download PDF
Full Install Guide

Camera features

  • Image Sensor
    1 / 2.8" Progressive CMOS
  • Sensor Resolution1
    5MP (2688 x 1944)
  • Lens Type
    Fixed
  • Focal Length
    2.8mm
  • Aperture
    F1.6
  • Iris
    Fixed
  • Field of View (after LDC2)
    Horizontal: 97° (78°)
    Vertical: 71° (63°)
    Diagonal: 128° (91°)
  • Sensor Movement
    Tilt: 70°
    Pan: 355°
    Rotation: 240°
  • Shutter Speed
    1 / 30 sec. to 1 / 10,000 sec.
  • Day/Night
    IR-cut filter for day and night function
  • IR Cut Filter
    Yes
  • IR Range
    15m / 49ft
  • Minimum Illumination
    0.009 lux @ F1.9 (Color)
    0 lux with IR Illuminators on
  • Onboard Storage
    Capacity: From 128GB to 2TB
    Card: MicroSD, SDXC
  • CPU
    Ambarella S5L63

Standard video settings

  • Compression
    H.265, H.264
  • Frame Rate4
    24fps
  • Live Streaming Settings
    High quality (HQ): Up to 3,000 Kbps (default)
    Standard quality (SQ): Up to 600 Kbps
  • Historical Video Settings
    Adaptive quality1

Standard audio settings

  • Audio
    Supported
  • Audio Capacity
    One-way audio
  • Interface
    Built-in microphone
  • Effective Range
    5m / 15ft

Power and network

  • Power Input3
    With IR: IEEE 802.3af Type 1 PoE
    Without IR: IEEE 802.3af Type 1 PoE
    Extended temperature range: IEEE 802.3af Type 1 PoE
  • Power Consumption
    With IR: 37-57V, 0.14-0.09A, 5.46W
    Without IR: 37-57V, 0.08-0.05A, 3.22W
    Extended temperature range: 37-57V, 0.27-0.17A, 10.1W
  • Connectivity
    RJ-45 cable connector for network/PoE connection; 10 / 100 Mbps
  • RTSP
    RTSP 1.0
    RFC 2326
    Max concurrent streams: 2
    Audio support: Yes

General

  • Operating Temperature
    -40°C to 55°C / 40°F to 131°F
  • Humidity
    0 to 90%
  • Certifications
    For hardware certification information, please visit verkada.com/compliance
  • LED Indicator
    System power and status indicator
  • Warranty
    10 Years
  • Included Accessories
    Setup guide, T10 security torx screwdriver, wall mount screws (3x), junction box screws (2x), mounting template, desiccant bags, cable sealing components

Mechanical

  • Weight
    Camera: 401g / 14.14oz
    Mount plate: 138g / 4.87oz
  • Dimensions
    Ø: 121mm / 4.78in, H: 72mm / 2.83in
  • Body
    Aluminum, plastic dome trim

Software capabilities

  • Alerts
    Camera status, motion detection, people detection, vehicle detection, Person of Interest detection, crowd detection
  • Streaming and storage
    Cloud backup, configurable retention days, selectable storage location, low bandwidth mode, timelapse, RTSP
  • People analytics
    People search, attribute search, face search, motion search, trajectory analysis, selective face blurring, AI-powered search5
  • Sharing and privacy
    Live link, privacy regions, audit log
  • Vehicle analytics
    Vehicle search, attribute search, motion search, AI-powered search5

1 All our cameras record in "adaptive quality", capturing both standard and high quality streams. Standard quality (SQ) video is stored up to the amount of retention specified by the customer. The amount of high quality video stored on the camera will depend on the amount of motion detected by the camera over time. To learn more, visit our website: https://docs.verkada.com/docs/adaptive-quality-recording-whitepaper.pdf

2 Lens Distortion Correction (LDC) crops the sensor field of view to deliver a rectified, undistorted output image.

3 Extended temperature range includes operating temperatures below -8.5°C / 16.7°F and assumes IR will be enabled.

4 Frame rate can be adjusted by support.

5 AI-powered search is currently supported in English only.
