CD52-E Outdoor Dome

High resolution, general purpose indoor dome with intelligent edge-based video analytics.

5MP

Image Resolution

3x

Optical Zoom

IP67

and IK10 Rated

30M

Image Resolution

Accessory List

Wall Mounting

ACC-MNT-ARM-1

Arm Mount

Wall mounted extender arm with built in 1.5” female NPT thread.

ACC-MNT-8

Pendant Cap Mount Kit

Threaded cap that attaches to the rear of a camera.

ACC-MNT-3

Wall Mounted L-Shaped Bracket Kit

Compact bracket for mounting camera perpendicular to wall.

ACC-CAM-SHIELD-1

Camera Weather Shield

Weather shield for protecting the camera against external elements.

ACC-MNT-POLE-1

Pole Mount

For mounting cameras to circular poles 2″ to 6″ in diameter.

ACC-CAM-SHIELD-1

Camera Weather Shield

Weather shield for protecting the camera against external elements.

ACC-MNT-POLE-1

Pole Mount

For mounting cameras to circular poles 2″ to 6″ in diameter.

ACC-MNT-ARM-1

Arm Mount

Wall mounted extender arm with built in 1.5” female NPT thread.

ACC-MNT-8

Pendant Cap Mount Kit

Threaded cap that attaches to the rear of a camera.

ACC-MNT-CORNER-1

Corner Mount

Mount for installing cameras and accessories to external corners.

ACC-CAM-SHIELD-1

Camera Weather Shield

Weather shield for protecting the camera against external elements.

ACC-MNT-CORNER-1

Corner Mount

Mount for installing cameras and accessories to external corners.

ACC-MNT-ARM-1

Arm Mount

Wall mounted extender arm with built in 1.5” female NPT thread.

ACC-MNT-8

Pendant Cap Mount Kit

Threaded cap that attaches to the rear of a camera.

Product Specifications

Product Specifications

Download PDF
Full Install Guide

Camera features

  • Image Sensor
    1 / 2.8″ Progressive CMOS
  • Sensor Resolution1
    5MP (2688 x 1944)
  • Lens Type
    Varifocal; motorized zoom
  • Focal Length
    2.8 - 8mm
  • Aperture
    F1.3 - F2.4
  • Iris
    P-Iris
  • Field of View (after LDC2)
    Horizontal: 105° - 38° (84° - 37°)
    Vertical: 77° - 29° (68° - 28°)
    Diagonal: 126° - 48° (97° - 45°)
  • Sensor Movement
    Tilt: 60°
    Pan: 355°
    Rotation: 350°
  • Shutter Speed
    1 / 30 sec. to 1 / 10,000 sec.
  • Day/Night
    IR-cut filter for day and night function
  • IR Cut Filter
    Yes
  • IR Range
    30m / 98ft
  • Minimum Illumination
    0.009 lux @ F1.9 (Color)
    0 lux with IR Illuminators on
  • Onboard Storage
    Capacity: From 256GB to 2TB
    Card: MicroSD, SDXC
  • CPU
    Ambarella CV25S88

Standard video settings

  • Compression
    H.265, H.264
  • Frame Rate4
    24fps
  • Live Streaming Settings
    High quality (HQ): Up to 3,000 Kbps (default)
    Standard quality (SQ): Up to 600 Kbps
  • Historical Video Settings
    Adaptive quality1

Standard audio settings

  • Audio
    Supported
  • Audio Capacity
    One-way audio
  • Interface
    Built-in microphone
  • Effective Range
    5m / 15ft

Power and network

  • Power Input3
    With IR: IEEE 802.3af Type 1 PoE
    Without IR: IEEE 802.3af Type 1 PoE
    Extended temperature range: IEEE 802.3at Type 2 PoE+
  • Power Consumption3
    With IR: 37-57V. 0.3-0.2A, 10.98W
    Without IR: 37-57V, 0.13-0.08A, 4.74W
    Extended temperature range: 37-57V, 0.43-0.28A, 16.03W
  • Connectivity
    RJ-45 cable connector for network/PoE connection; 10 / 100 Mbps
  • RTSP
    RTSP 1.0
    RFC 2326
    Max concurrent streams: 2
    Audio support: Yes

General

  • Operating Temperature
    -40°C to 50°C / -40°F to 122°F
  • Humidity
    0 to 90%
  • Certifications
    For hardware certification information, please visit verkada.com/compliance
  • LED Indicator
    System power and status indicator
  • Warranty
    10 Years
  • Included Accessories
    Setup guide, wall mount screws & anchors (4x), T10 security torx screwdriver, mounting template, cable gland wrench, desiccant pack, conduit adapter

Mechanical

  • Weight
    Camera: 1070g / 37.74oz
    Mount plate: 174g / 6.14oz
  • Dimensions
    Ø: 155mm / 6.10in, H: 114.6mm / 4.51in with mount plate
    Ø: 155mm / 6.10in, H: 107.6mm / 4.24in without mount plate
  • Body
    Aluminum, plastic dome trim

Software capabilities

  • Alerts
    Camera status, motion detection, people detection, vehicle detection, Person of Interest detection, crowd detection, line-crossing detection, loitering detection
  • Streaming and storage
    Cloud backup, configurable retention days, selectable storage location, low bandwidth mode, timelapse, RTSP
  • People analytics
    People search, attribute search, face search, Occupancy Trends, motion search, trajectory analysis, selective face blurring, AI-powered search5
  • Sharing and privacy
    Live Links, live face blur, privacy regions, audit log
  • Vehicle analytics
    Vehicle search, attribute search, motion search, trajectory analysis, Occupancy Trends, AI-powered search5

1 All our cameras record in "adaptive quality", capturing both standard and high quality streams. Standard quality (SQ) video is stored up to the amount of retention specified by the customer. The amount of high quality video stored on the camera will depend on the amount of motion detected by the camera over time. To learn more, visit our website: https://docs.verkada.com/docs/adaptive-quality-recording-whitepaper.pdf

2 Lens Distortion Correction (LDC) crops the sensor field of view to deliver a rectified, undistorted output image.

3 Extended temperature range includes operating temperatures below -8.5°C / 16.7°F and assumes IR will be enabled.

4 Frame rate can be adjusted by support.

5 AI-powered search is currently supported in English only.
