AC62 Door Controller
Verkada’s AC62 is an enterprise-ready access panel for access controlling up to 16 doors on a unit. Beyond scale, the AC62 seamlessly integrates with existing systems of readers, AUX relays and fire alarm interface panels. Like the rest of the Verkada suite, the AC62 integrates natively with Verkada Command for simplified, cloud-based management.
Access Control Capabilities For 16 Doors
Supports Verkada and Weigand Readers
Fire Alarm Interface Support
Native Cloud
Integration
Integration
Enterprise-Scale Access Control
Bring the functionality of native cloud-based access control and video security solution to more doors across campuses, offices and more.
Make all entry decisions for 16 doors across sites, floors and access levels from a single unit.
Connect inputs to Verkada readers, 3rd party Wiegand readers, AUXs, DPIs and FAIs for greater efficiency.
Get the scale and simplicity of the cloud on an enterprise-scale access controller.
Frequently Asked Questions
What is the AC62 door controller?
The AC62 is a 16 door access controller that allows customers to seamlessly access control 16 doors on one controller and manage everything from Verkada Command, a simplified cloud-based hub. Customers can utilize the AC62 to connect up 16 hardwired doors with door readers, door strikes, mag locks or other door hardware. In addition to natively connecting with Verkada’s AD32 door reader, the AC62 also integrates with 3rd party readers that utilize the Wiegand communication interface. This includes readers from HID and others.
What is the AC62 FAI Connection?
The AC62 also includes a Fire Alarm Interface (FAI). The FAI on the AC62 can power down door locks when a signal from a Fire Alarm Control Panel (FACP) is received. In other words, the AC62 will de-energize powered locks in case of the fire emergency to unlock fail safe doors. The most common use case is to remove power from maglocks when a fire alarm occurs, allowing for faster egress and firefighter access.
What hardware features does the AC62 offer?
The Verkada AC62 offers simplified access hardware from installation to daily use. The AC62 connects to Verkada Command via ethernet connection – no servers, thick or thin clients required. At the same time, intentional design helps ensure a simple and safe install – including detachable wiring terminals, a lightweight wall mount plate and a wiring annotation diagram.
Why does the AC62 have detachable wiring terminals?
The AC62’s detachable wiring terminals allow for fast and simplified installation, and the elegant mounting bracket design allows installers to size and place the unit effortlessly. Lastly, as a unified 16 door controller, the AC62 minimizes the hardware footprint of access control systems, allowing for more space conscious deployments.
Product Specifications
- Power Consumption60W maximum
- AC Power Input100-240VAC
50/60Hz
1.5A maximum - Inputs2x REX dry inputs per door
1x DPI dry input per door
2x auxiliary dry inputs - AUX Power1x 12V @ 250mA
- Readers1x reader port (Verkada/RS-485 or Wiegand) per door
Reader current consumption must be < 250mA per reader
Note: max of 4 readers can be powered simultaneously - Relay Outputs1x wet or dry relay per door
Wet relay switch-selectable power:
- 12V operation 700mA max
- 24V operation 350mA max
- 24VDC @ 2A (resistive load)
- DimensionsHeight: 417.0mm / 16.4in
Width: 321.omm / 12.6in
Depth: 116.3mm / 4.6in - Weight6.4kg / 13.9lbs
- Operating Temperature0°C - 50°C
5 - 90% Humidity - ComplianceFor hardware certification information, please visit verkada.com/compliance
- ConnectivityEthernet: 10/100Mbps RJ-45 for network connectionUSB 2.0
- Included AccessoriesLock key and flat head screwdriver
